Epson SureColor SC-F9270 Dye-Sublimation Textile Production Printer

Product Models displayed on this website may be available in certain regions only.

Trendsetting Performance with Affordable and Quality Prints

Designed specifically for the purpose of dye-sublimation printing, it combines the speed, precision and durability of PrecisionCore printhead technology with an original dual 1.5L ink tank system to deliver amazing performance for highly efficient and reliable production runs.

    • 64-inch high performance roll-to-roll dye-sublimation printer
      Designed for true industrial-level roll-based production
      Large 2x 1.5L capacity ink tank per colour
      High performance with dual printheads with maximum print speed of just over 100sqm per hour
      Ideal for medium to large-volume roll-to-roll custom fabric, textile and soft signage



Remarkable Productivity
Engineered to operate with minimum downtime at continuous operations, Epson SureColor™ SC-F9270 delivers superior print quality at high speeds with its dual PrecisionCore™ printheads and its groundbreaking original ink tank system. You can expect fast production turnaround with class-leading speeds of up to 100.1m2/h and productivity features such as automatic take-up reel and post heater.

Affordable Prints with Peace of Mind
Epson’s commitment to product quality ensures you a peace of mind with warranty coverage of one year, inclusive of the printheads. Experience swift and reliable high-volume printing with a winning combination of Epson’s printhead technology, UltraChromeTM DS ink and original ink tank system. Low machine maintenance and minimal downtime means you get to maximize savings with a printer designed specifically for the purpose of dye-sublimation printing.

Consistently Vibrant Quality
Expect to produce vibrant and sharp colour images, with UltraChrome DS ink, which have excellent light and wash-fastness as well as resistance to alkaline and acid perspiration.

Epson UltraChrome DS ink contributes to a healthy work environment with its 100% nickel and fluorine-free formulation that allows for printed textile and garments to be certified safe for use for babies and toddlers up to 3 years old in accordance with OEKO-TEX® Standard 100 Class 1 criteria.

Designed for Convenience
With convenience spelled into both the printer’s standard bundled industry-leading RIP software as well as its intuitive design, you can easily manage print layouts and colours digitally as well as access all major functions and features like the ink tank system, control panel and take-up reel control.

Print:


Printing Technology: Dual PrecisionCore™ TFP® Print Heads
Continuous Ink Supply System, 3.0L High-Capacity Tanks
Epson UltraChrome DS Ink, 4 Color Ink Set
True Roll-to-Roll dye-sublimation printing technologyMaximum Print Resolution: 1440 x 720 dpi; 720 x 720 dpi; 720 x 360 dpiPrint Speed: Speed (720 x 360 dpi) 1044 SFPH
Production (720 x 720 dpi) 615 SFPH
High Quality (1440 x 720 dpi) 172 SFPHNozzle Configuration: 1440 nozzles per Color with Variable Droplet Size
Minimum drop size is 5.3 picoliters

Ink:


Ink Type: Ink Supply System-chip1Replacement Ink: UltraChrome DS Ink
● High Density Black Ink Packs (T741X00)
● Cyan Ink Packs (T741200)
● Magenta Ink Packs (T220320)
● Yellow Ink Packs (T741400)

See Note2

Ink Supply System:


Ink Supply Fill Volume: 3000 mL each color x 4 colors totalIn-box Ink Fill Volume: 2000 mL each color x 4 colors totalRetail Ink Fill Volume: 6 x 1000 mL ink pack for each color x 4 colors totalInk Shelf Life: 2 years from printed production date Printer is designed for use with Epson ink packs only, not third-party ink systems.

Printable Area and Accuracy:


Maximum Paper Width: 64-inchMinimum Paper Width: 12-inch rollMaximum Printable Width: 63.60-inches

General:


System Requirements: Windows 7, Windows 8, or Windows 10
2GHz CPU
2GB RAM

Printer Details:


Software Included: Epson Professional Communication Driver for Windows
Epson LFP Remote Panel 2
Epson Net Config

Power:


Rated Voltage: AC 100-240 VRated Frequency: 50-60HzPower Requirements: Operating Approx. 760W
Ready Approx. 458W (Heater ON)
Standby Approx. 38W (Heater OFF)Rated Current: 10A
See Full Specs Hide Full Specs

Notes:

1The SureColor F-Series printers are designed to be used exclusively with UltraChrome DS inks and not with any other brands of cartridges or inks. Using Epson genuine ink is important for reliable performance and high image quality.

2Oeko-Tex 100 (Product Class 1) - The four color Epson dye sublimation inks used in the Epson SureColor F6200 printer, when applied to polyester fabrics, pass the requirements of Oeko-Tex Standard 100 for human ecological requirements of Class 1 products for adults, children, and babies up to 36 months. Oeko-Tex Standard 100 specifies testing criteria for the presence of harmful substances within a textile product. The standard belongs to the International Association for Research and Testing in the field of Textile Ecology (Oeko-Tex)
