Epson SureColor SC-F9270 Dye-Sublimation Textile Production Printer

Product Models displayed on this website may be available in certain regions only.

Trendsetting Performance with Affordable and Quality Prints

Designed specifically for the purpose of dye-sublimation printing, it combines the speed, precision and durability of PrecisionCore printhead technology with an original dual 1.5L ink tank system to deliver amazing performance for highly efficient and reliable production runs.

      • 64-inch high performance roll-to-roll dye-sublimation printer
      • Designed for true industrial-level roll-based production
      • Large 2x 1.5L capacity ink tank per colour
      • High performance with dual printheads with maximum print speed of just over 100sqm per hour
      • Ideal for medium to large-volume roll-to-roll custom fabric, textile and soft signage



      Click here to register for Epson Cloud Solution PORT.
Where to Buy

Remarkable Productivity
Engineered to operate with minimum downtime at continuous operations, Epson SureColor™ SC-F9270 delivers superior print quality at high speeds with its dual PrecisionCore™ printheads and its groundbreaking original ink tank system. You can expect fast production turnaround with class-leading speeds of up to 100.1m2/h and productivity features such as automatic take-up reel and post heater.

Affordable Prints with Peace of Mind
Epson’s commitment to product quality ensures you a peace of mind with warranty coverage of one year, inclusive of the printheads. Experience swift and reliable high-volume printing with a winning combination of Epson’s printhead technology, UltraChrome™ DS ink and original ink tank system. Low machine maintenance and minimal downtime means you get to maximize savings with a printer designed specifically for the purpose of dye-sublimation printing.

Consistently Vibrant Quality
Expect to produce vibrant and sharp colour images, with UltraChrome DS ink, which have excellent light and wash-fastness as well as resistance to alkaline and acid perspiration.

Epson UltraChrome DS ink contributes to a healthy work environment with its 100% nickel and fluorine-free formulation that allows for printed textile and garments to be certified safe for use for babies and toddlers up to 3 years old in accordance with OEKO-TEX® Standard 100 Class 1 criteria.

Designed for Convenience
With convenience spelled into both the printer’s standard bundled industry-leading RIP software as well as its intuitive design, you can easily manage print layouts and colours digitally as well as access all major functions and features like the ink tank system, control panel and take-up reel control.


Printing Technology: Dual PrecisionCore™ TFP® PrintheadNozzle Configuration: 2 x 360 x 2 nozzles each colour (x4)Print Direction: Bi-directional printing, uni-directional printingMaximum Print Resolution: 720 x 1440 dpiMinimum Ink Droplet Size: 5.3 pl, with Variable-Sized Droplet TechnologyPrint Speed: (Print Mode: Draft / Resolution: 360 x 720 / Pass: 1) 100.1 m2/h
(Print Mode: High Speed / Resolution: 720 x 720 / Pass: 2) 57.0 m2/h
(Print Mode: Production / Resolution: 720 x 720 / Pass: 3) 46.9 m2/h
(Print Mode: Production / Resolution: 720 x 720 / Pass: 4) 30.0 m2/h
(Print Mode: High Quality / Resolution: 720 x 720 / Pass: 6) 19.6 m2/h
(Print Mode: High Quality / Resolution: 720 x 1440 / Pass: 8) 14.9 m2/h


Ink Type: Epson UltraChrome™ DS Ink TechnologyInk Capacity: Tank: 2 x 1500ml per colour
Pack: 1000mlInk Configuration: Cyan, Magenta, Yellow, High Density Black


Bundled Items: Substrate Support System and Ink Supply System - C12C932431
Initial Ink Pack Set - C12C932461Optional: Waste Ink Bottle - C13T724000
Maintenance Kit - C13S210038
Media Holding Plate - C12C932121

Paper Handling:

Media Width: 300mm (11.8") to 1625mm (64")Paper Feed Method: Rear roll feed (2"/3" core with max 250mm diameter and up to 40kg); Auto take-up reelPrint Margin: Max. 1615.6mm
Side Margin: 5mm both sides (10mm when using Media Holding Plates)Media Thickness: 0.08 – 1.0mm (Over 75g/m2)

Control Panel:

Colour & Size: 2.5" Colour LCD


Main: 512MBNetwork: 128MB

Printer Software on CD-ROM:

Printer Drivers: Communication Driver, User’s Guide, EPSON LFP Remote Panel 2, EpsonNet Setup, EpsonNet Config, EpsonNet Print, Wasatch SoftRIP

Control Code:

Control Code: ESC/P raster

Electrical Specifications:

Rated Voltage: AC 100 – 240VRated Frequency: 50 – 60HzOperating: Approx. 485WSleep: Approx. 11WPower Off: Less than 1WStandby: Approx. 38W with Heater OFFPower Supply: 10 – 5A

Power Consumption:

Operating: Approx. 485WStandby: Approx. 38W with Heater OFFSleep: Approx. 11WPower Off: Less than 1W

Recommended Operating Temperature & Humidity:

Recommended Operating Temperature & Humidity: 15 - 35°C, 20 - 80% RH (non-condensing)

Printer Software:

Printer Software: (on CD-ROM) Communication Driver, User’s Guide, EPSON LFP Remote Panel 2, EpsonNet Setup, EpsonNet Config, EpsonNet Print, Wasatch SoftRIP


Standard: USB 2.0 Hi-SpeedEthernet: 10BASE-T / 100BASE-TX / 1000BASE-T


1The SureColor F-Series printers are designed to be used exclusively with UltraChrome DS inks and not with any other brands of cartridges or inks. Using Epson genuine ink is important for reliable performance and high image quality.

2Oeko-Tex 100 (Product Class 1) - The four color Epson dye sublimation inks used in the Epson SureColor F6200 printer, when applied to polyester fabrics, pass the requirements of Oeko-Tex Standard 100 for human ecological requirements of Class 1 products for adults, children, and babies up to 36 months. Oeko-Tex Standard 100 specifies testing criteria for the presence of harmful substances within a textile product. The standard belongs to the International Association for Research and Testing in the field of Textile Ecology (Oeko-Tex)
