Epson Moverio Pro BT-2000 Smart Headset

Product Models displayed on this website may be available in certain regions only.

Optimised for Enterprise Usage

Featuring a series of technology and design innovations designed specifically for the industrial workplace, the revolutionary BT-2000 smart headset is poised to improve operational efficiency and ultimately change how work gets done.

  • Depth-Sensing Camera
  • Industrial Grade IMU Sensor
  • Binocular, Transparent Lenses
  • Brighter Display


Experience a Smarter Workplace

The Epson Moverio Pro BT-2000 Smart Headset was designed for advanced augmented reality applications, remote field support, and any hands-free applications that require an industrial strength smart eyewear solution.

What's in the box:

Battery pack
AC Adapter with cable
Shade (Dark) x 1 Protective Shield (Clear)
Lens holder
Mono earphones w/Mic Controller holder
Arm band
Reel clip
Hexagonal wrench and Screw
User Manual
Inner pads x 3 sizes

Wearable Device Details:

Model Type: See-Through Binocular Smart HeadsetBattery Life: Approx. 4 hours (with hot-swappable feature)Battery Type: Lithium-ion batteries 1240 mAh / 7.4 V (x 2 cells)Water Proof: Headset and Controller: Water and dust resistant (IP54)Dimensions Headset: 205 x 136 x 100 mm (without the head band)Dimensions Controller: 70 x 35.3 x 157 mmWeight Headset: 290 g (without cables)Weight Controller: 265 g (without batteries, 1 battery is approx. 50g)Operating Temperature: 0 to 40 °C, 20 to 80 % humidity (no condensation)Storage Temperature: -10 °C to 60 °C, 10 % to 90 % humidity (no condensation)Power Supply Voltage Controller: 11 V DC, (1.64 A) via DC adapterPower Supply Voltage AC Adapter: 100 to 240 V AC, 50 to 60 Hz, 0.4 A


Display Device Type: HTPS LCD (High Temperature Poly-Silicon Liquid Crystal Display)Driving Method: Polysilicon Thin Film Transistor Active MatrixRefresh Rate: 60 HzField of View: 23 ° (Diagonal)Screen Size (Projected Distance): 40-inch at 2.5 m, 320-inch at 20 mDisplay Size: 0.42 inch wide panel (16:9)Pixel Number: 518,400 pixels (960 x 540)

Android Platform:

OS Version: Android 4.0.4Pre-Installed Applications: BLEBeacon, Browser, CameraTest, Downloads, FMP_PXP, Gallery, Search, SelfDiagnosis, Settings, SEViewer, VoiceCommand


Camera - Image Capturing: 5MP (Still image: 2596 x 1948, Video: 1920 x 1080)Camera - Depth Sensing: 640 x 480 (Approx. Range: 30-100cm)GPS: Yes, in HeadsetCompass: Yes, 3-axis in ControllerGyroscope: Yes, 3-axis in Headset, IMU (+/- 450 deg/sec)Accelometer: Yes, 3-axis in Headset, IMU (+/- 6 G)Ambient Light Sensor: Yes (0 - 65,528 lux)

CPU and Memory:

CPU: TI OMAP4460RAM: 1 GBInternal Storage: 8 GB

Supported File Formats:

Video: MP4 (MPEG4 + AAC), MPEG2 (H.264 + AAC)Picture: JPEG, PNG, BMP, GIFAudio: WAV, MP3, AAC3D Supports: Side by Side

Sound Output:

Maximum Audio Output Level: 150 mV


USB Interface: Micro USB type B, USB 2.0 (device / host)Network: IEEE 802.11 a/b/g/n with WiFi certified
Modulation: OFDM, DSSSBluetooth: Bluetooth 3.0 (HSP / A2DP / HID / OPP / SPP / AVRCP)
Bluetooth 4.0 LE, (PXP / FMP)
*Can be used with Epson specified beacon device.SD Card Slot: MicroSD (max. 2 GB) / MicroSDHC (max. 32 GB)Audio Jack: 3.5 mm 4 pole mini-jack, CTIA type
